PTC ICL Inquiry

Questionary for Design-In of Inrush Current Limiter PTC

Please complete this form and send it to us. Don't forget to select the country so that your inquiry can be addressed directly to the responsible contact person.

Circuit Diagram

Single-phase supply with single-phase bridge rectifier

V_max = V_rms

V_{link, max} = V_DC

Three-phase supply with three phase bridge rectifier

V_max = V_rms

V_{link, max} = V_DC

DC-Circuit

V_{link, max} = V_DC

Other (please specify)

Remark

General Parameters

Capacitance of DC Link (or smoothing) capacitor

C = µF

Minimum / maximum ambient temperature at the charging process

T_Amin = °C

T_Amax = °C

Max. allowed inrush current peak (if specified)

I_Pmax = A_p

Max. charging time (if specified)

t_max = s

Number of repetitive charging cycles within short time period (if specified)

n = cycles per minute

Number of expected charging cycles over life time

n = cycles

Other requirements (please specify)
